Implementing Cisco Service Provider VPN Services (300-515 SPVI) Exam (300-515) - Cisco Exam Questions

Last updated on June 20, 2026

97% Exam Compliance
71 Total Questions
1
Question
Exhibit

An organization is running H-VPLS on a network comprising four routers in a hub-and-spoke topology Refer to the exhibit. with R1 as the hub An engineer added a new spoke with multiple VCs to the network, and now traffic cannot flow properly How should the engineer update the configuration on R1 to correct the problem?
Options
A Disable Cisco Discovery Protocol to allow MPLS to share labels between the designated spokes
B Disable Cisco Discovery Protocol to allow for neighbor discovery
C Disable split horizon to allow multiple VCs per spoke
D Disable spanning tree to allow loops to occur within the hub-and-spoke topology.
Discussion (0 comments)

to join the discussion

Community Discussion

No discussions yet. Be the first to ask!

2
Question
The CTO of a company requires the support of a network consultant to deliver an MPLS solution without resigning to a certain degree of redundancy and scalability. Which solution effectively scales to hundreds or thousands of sites?
Options
A L3VPN with direct LSP connectivity between all PEs.
B L3VPN using a hierarchical topology of N-PEs and U-PEs.
C L2VPN by encapsulating multiple frame formats with interworking.
D L2VPN with the broadcast traffic processed at the ingress PE.
Discussion (0 comments)

to join the discussion

Community Discussion

No discussions yet. Be the first to ask!

3
Question
Refer to the exhibit.

Exhibit

A network operator is implementing EVPN IRB on PE1. Which two command placements enable the advertisement of Type 2 routes and what information do Type 2 routes contain? (Choose two.)
Select 2
Options
A Type 2 routes contain Ethernet Auto-Discovery information.
B Type 2 routes contain inclusive source-specific multicast route information.
C Type 2 routes contain MAC/IP information.
D The operator adds in “host-routing” under the BVI651 interface.
E The operator adds in “host-routing” under the VRF EVPN.
Discussion (0 comments)

to join the discussion

Community Discussion

No discussions yet. Be the first to ask!

4
Question
Which two statements about MPLS L3 VPN RDs are true? (Choose two.)
Select 2
Options
A They enable EIGRP to use address families to separate traffic between IPv4 and VPNv4.
B They allow BGP to uniquely identify duplicate routes.
C They enable OSPF to import and export routes into the global routing table of a router.
D They are represented as 64-bit values.
E They are represented as 32-bit values
Discussion (0 comments)

to join the discussion

Community Discussion

No discussions yet. Be the first to ask!

5
Question
Refer to the exhibit.

Exhibit

Which statement describes the result of this configuration?
Options
A R1 redistributes BGP routes into the OSPF process of VRF custabc as E2 routes.
B R1 redistributes BGP routes into the OSPF process of VRF custabc as OIA routes.
C R1 mutually redistributes routes between BGP 65001 and the OSPF process of VRF custabc.
D R1 redistributes BGP routes into the OSPF process of VRF custabc as E1 routes.
Discussion (0 comments)

to join the discussion

Community Discussion

No discussions yet. Be the first to ask!
